4K Game Capture Station

Model: JVA14-N
1.999,00 kr

The JVA14 4K Game Capture Station is a capture device designed to stream and record your gameplay. It supports 4K @ 30 FPS video capture with 4K @ 60 FPS passthrough for consoles capable of 4K resolution. It has a 3.5 mm Audio In port and Mic In port allowing a headset to be connected for live commentary streaming on PlayStation™ 4 / 5, Xbox™ Series X / S, Xbox™ One X / S. It is fully compatible with OBS™ and other video streaming software, making it perfect for live streaming. The JVA14 is plug-and-play and compatible with macOS® and Windows® laptops and desktops.







Supports 4K capture and 4K60 HDR pass-through

View your gameplay at high resolutions with the 4K capture and 4K HDR pass-through

Perfect for live streaming and recording gameplay

Compatible with OBS™, XSplit®, CameraFi™, QuickTime®, and other video streaming software. Suitable for gaming consoles such as PlayStation™ 4/5, Xbox™ Series X/S, Xbox™ One X / S and Switch™

Quality Audio Connectivity

The JVA14 features a flexible audio connection via HDMI™ or analog 3.5 mm ports so you can record audio directly from game consoles, computers, or output to speakers/mixers

Low-latency streaming with a USB™ 3.2 connection

High-speed USB™ connection allows for quick data transfer and high quality streaming

60W Power Delivery 3.0

Allows phones and laptops with USB-C® power delivery to stay charged while being used as a streaming device

Easy DSLR attachment with 2 cold shoes embedded

LED indicator to keep track of USB™ speeds and compression rates

- USB™ 3.0 connection: Purple
- USB™ 2.0 connection: Blue
- Power Only: Orange

No driver installation required

  • Uncompressed 4K@30 Capture + 4K@60 Loop Out
  • 4K60 pass-through support (Uncompressed)
  • Power Only: Orange
  • No driver installation required
  • HDR Passthrough: Supports resolutions up to 4K @ 60 Hz, 1440p @ 144 Hz, and 1080p @ 240 Hz
  • Ultra-low latency stream with high-performance USB-C® 3.2 connection
  • LED indicator to keep track of USB™ speeds and compression rates
    • USB™ 3.0 connection: Purple (Uncompressed)
    • USB™ 2.0 connection: Blue (Uncompressed)
Hardware
audio input

1 - 3.5mm AUX

audio output

1 - 3.5mm AUX

audio switcher
N/A
host connector

1 - USB-C® 3.2 Female

ports

1 - USB-C® 3.2 Gen 1

1 - HDMI™ Input

1 - HDMI™ Output

1 - Audio Out (3.5 mm)

1 - Mic In (3.5 mm)

power source
Bus-powered
video input

1 - HDMI™ Female

video output

1 - HDMI™ Female

video switcher
N/A
warranty
2 Year Limited
Performance
audio channel
2.1 via HDMI™
audio frequency

48 kHz

format
USB™ 3.0: RGB / YUV4:2:2 / YUV4:2:0
USB™ 2.0: YUV4:2:0
hdr supported
Yes
headset

2.1 Stereo

maximum capture capability
USB™ 3.0: 3840 x 2160 @ 30
USB™ 2.0: 1280 x 720 @ 30
maximum capture refresh rate
4K30 FPS, 2K60 FPS, 1080p120 FPS
maximum capture resolution
3840 x 2160
maximum passthrough resolution
3840 x 2160
max passthrough refresh rate
4K60 Hz HDR, 2K144 Hz HDR, 1080p240 Hz HDR
microphone

Stereo microphone supported

24-bit sigma-delta ADC

Mouse Specifications
Power
power consumption
≤900 mA
power delivery
60W via USB-C®
Physical Specifications
cable length
3.3 ft (1m)
color
Black
enclosure type
Aluminum
operating humidity
<80% non-condensing
operating temperature
32 to 104°F (0 to 40°C)
product depth
0.7 in. (18.4 mm)
product height
2.5 in. (63.7 mm)
product weight
5.03 oz (142.5g)
product width
5.3 in. (134.6 mm)
storage humidity
<85% non-condensing
storage temperature
14 to 149°F (-10 to 65°C)
Wireless Protocols
Package Contents
  • 1 - JVA14 4K Game Capture Station
  • 1 - USB-C® 3.0 to USB™ Type-A cable 1.96 ft / 60 cm
  • 1 - USB-C® 3.0 to USB-C® cable 1.96 ft / 60 cm
  • 1 - HDMI™ 2.0 cable 3.3 ft / 1m
  • 1 - Quick Installation Guide (QIG)
System Requirements
  • Available USB-C® or USB™ Type-A port (USB™ 3.2 / 3.0 is recommended)
  • Windows® 7 or later
    macOS® 10.12 or later
    Android™ 8.1 or later
  • CPU: Intel® Core™ i7 6700HQ & above
  • GPU: NVIDA® GTX 960M & above
  • RAM: 8 GB or higher
Special Notes
  • N/A
